Polyworks Modeler

PolyWorks|Modeler™ is a comprehensive reverse engineering software solution that allows extracting optimal CAD entities—curves, surfaces, parametric sketches, and prismatic features—from polygonal models of digitized parts to serve as the starting point in your professional CAD modeling solution.

The first step in a reverse-engineering workflow consists in transforming digitized point clouds into surface-based polygonal models, also called meshes. Polygonal models are more compact, more accurate, and less noisy than raw point clouds and are directly handled by industrial applications such as milling, 3D printing, and aerodynamic simulation.

NURBS surfaces are lightweight representations of simple features and organic shapes commonly used to replicate and transfer polygonal surfaces built from point cloud data to CAD/CAM software. PolyWorks|Modeler™ offers an intuitive surfacing workflow that cleverly combines interactive curve creation with a next-generation automatic surfacing technology to generate editable CAD-friendly models for your simulation, machining, and design applications.

• Create polygonal models of digitized parts in real time
• Repair and optimize imperfectly digitized geometry
• Apply CAD operations to polygonal models
